Separating responsibility in performance traces ⚖️

Performance trace responsibility

In Part 2, I focused on attribution: figuring out which process and thread did the work.

That unlocked an important question I couldn't ignore anymore:

When my app is slow, how much of that work is actually mine?

Part 3 is about responsibility.

The uncomfortable truth about performance 🧠

Every mobile engineer has felt this moment:

the UI thread is blocked
frames are janky
startup is slow

…and the trace looks terrifying.

But traces don't care about blame.

They happily mix together:

your app code
Android framework internals
system and kernel activity

Without separating those, it's easy to draw the wrong conclusions.

Part 3 is about making that separation explicit.

From "who did the work" to "what kind of work it was" 🧭

At the end of Part 2, the analyzer could already say:

which slices came from my app process
which thread they ran on
which app-defined sections dominated

But everything still lived in one bucket.

So in Part 3, I added a deterministic classification layer on top of that attribution.

Each slice is now labeled as one of:

🟢 app — work originating from app-defined sections
🔵 framework — Android UI / rendering / framework internals
🔴 system — scheduler, binder, SurfaceFlinger, kernel-level work
⚪ unknown — when we can't be confident

No AI. No guessing. Just rules.

Classification is conservative (on purpose) 🧪

This part matters.

The classifier is intentionally boring:

based on pid
based on thread ownership
based on small, explicit name-token rules

If a slice doesn't clearly belong to a category, it becomes "unknown".

That's not a failure — it's honesty.

Long tasks, now with responsibility labels 🧵

Here's what a long slice looks like now:

{
  "name": "UI#stall_button_click",
  "dur_ms": 200.1,
  "pid": 12345,
  "tid": 12345,
  "thread_name": "<main-thread>",
  "process_name": "com.example.tracetoy",
  "category": "app"
}

And a framework-heavy one:

{
  "name": "Choreographer#doFrame",
  "dur_ms": 450.3,
  "pid": 12345,
  "tid": 12345,
  "thread_name": "<main-thread>",
  "process_name": "com.example.tracetoy",
  "category": "framework"
}

Same trace. Very different implications.

Aggregates that change how you read traces 📊

Instead of eyeballing hundreds of slices, the analyzer now computes:

"work_breakdown": {
  "by_category_ms": {
    "app": 420.3,
    "framework": 1320.5,
    "system": 310.2,
    "unknown": 55.1
  }
}

This single block answers a powerful question:

Is this performance problem primarily app-owned?

Sometimes the answer is uncomfortable. Sometimes it's relieving.

Either way, it's grounded.

Main thread blocking: who's responsible? 🚦

The analyzer now breaks down main-thread blocking by category:

"main_thread_blocking": {
  "app_ms": 180.2,
  "framework_ms": 640.1,
  "system_ms": 95.0,
  "unknown_ms": 22.3
}

If framework dominates main-thread blocking, optimizing your app code alone won't fix the issue.

This doesn't assign blame — it just makes responsibility visible.

Summary output (quick orientation) 🧭

The analyzer now includes a summary block upfront:

"summary": {
  "dominant_work_category": "framework",
  "main_thread_blocked_by": "framework",
  "app_sections_found": 3
}

This gives you directional signals before diving into the details.

Not explanations. Not blame. Just orientation.

What this does NOT do 🚫

This classification system explicitly does not:

assign responsibility or blame
generate recommendations
claim causality
interpret developer intent

It simply makes responsibility visible through deterministic analysis.

What's next (Part 4) 🔮

In Part 4, I want to answer a different question:

When did this work actually matter?

That means:

breaking the trace into time windows (startup vs steady state)
correlating jank and stalls with those windows
surfacing "what to look at first" signals

Links 🔗

Repo: https://github.com/singhsume123/perfetto-agent

TraceToy test app: https://github.com/singhsume123?tab=repositories

Previous post (Part 2): https://substack.com/home/post/p-182558971

Part 1: https://substack.com/home/post/p-182552580

Closing thought 💭

Performance debugging isn't about blame.

It's about building an accurate mental model of who did what kind of work, where, and when.

Part 1 made traces readable. Part 2 made them attributable. Part 3 makes them separable by responsibility.

That's the foundation.
